The House of Industrial Rubber
The House of Industrial Rubber
Products
Rubber O-Rings
Description
O-Ring, the cutting edge is a “O” shape, which is the most common, classic, economical and useful sealing type in both dynamic and static application. To understand a basic idea of O-Ring, it is essential
you should know:
- The O-Ring dimension formula is very simple, OD = ID + 2*CS.
- The popular O-Ring standards are formulated by its location and country.
- The O-Ring tolerance has its limitation, when the size is out of tolerance; it means failure will cause leakage.
- O-Rings are made of elastomers which are with resilience or memory sufficient to return to its original shape after a major or minor distortion.
Application & Usage
Generally there are two types of O-Ring applications.They are Static and Dynamic application.
Static Application: In this the O-Ring is fitted between the two non-moving/static parts so that O-Ring remains static in assembly.
Dynamic Application: In this the O-Ring is fitted between the two moving/dynamic parts so that O-Ring remains will face the dynamic gland movement.
Materials Used
Nitrile Rubber (Buna-N), Silicone Rubber, Aflas, Fluoroelastomers like Viton A, B, GLT, GF, Fluorosilicone etc.), HNBR, Neoprene Rubber and AED applications etc.
- Full standard O-Ring series: AS 568, BS 4518, JIS B2401 P/G/S/V & METRIC.
Rubber Oil Seals
The function of the oil seal is to stop whatever fluid is inside from leaking out the clearance between the shaft and housing.
Description
An Oil Seal Normally Consists Of Three Basis Components:
Sealing Element, Metal Case, Spring. It is Widely Used Sealing Component. The Function Of A Seal Is To Prevent The Leakage Of Medium Along The Moving Parts. This Mainly Achieved By the Sealing Element.
The Material Normally Used Are Nitrile (Buna-N), Acrylic, Silicon & Fluorinated Rubber (FKM – Viton)
We Stock Mainly Nitrile (Buna- N) Oil Seals Used In Industries, Automotive, Agriculture & Mining Industries.
We have around 1000 ex stock Sizes of World Famous Brand TTO-Taiwan.
Rubber Cords
Rubber cord, often referred to as ‘rubber rope‘, is commonly used in various types of sealing applications where the exact size moulded O-ring is not available.
Description
Round rubber cord are a good alternative in areas where the sealing is not too aggressive or under very high pressure. These cords can be installed very easily in inaccessible work areas and can be joint on site with adequate adhesive. They provide sufficient resistance and elasticity in the sealing applications.
Our stock includes O-ring cords in a variety of materials including NITRILE (Buna-N), Viton & Silicone.
Ready Stock of Shore 70-75 A Is Available in All 3 polymers from 1.5mm to 50mm Diameter.
Different Hardness & Polymer Can be manufactured upon Request.
Rubber O-Ring Kits
O-Ring Kits consists of differents sizes of O-Rings which can useful in a situation when you don’t which O-Ring is required at the time
Description
O-ring kits can save hours of downtime especially in a crisis situation where part numbers are missing, or seal dimensions are not known, or the parts themselves are not available.
Our growing variety of different standard kits gives you a wide choice of sizes and materials for a broad range of sealing solutions. So you get multiple sealing solutions for the same cost as a single OEM replacement part. As the excellent O Ring kits suppliers, we also provide Viton and NBR O-RING Kits for the specific needs of our customers.
We Can Offer O-ring Kits,
- Standard size AS568 & Metric in Material NBR 70 duro, FKM75 duro.
Rubber Packings
Mainly used as water tight gaskets for the hatch covers in the shipping industry.
Description
Mainly used as water tight gaskets for the hatch covers in the shipping industry. These packing’s are manufactured in sponge rubber as well in solid rubber in a variety of hardness, ranging from 25 ± shore A to 85 ± shore A.
Rubber packing’s are manufactured in oil and weather resistant polymers such as Natural, SBR, Nitrile, and Mainly Soft in EPDM and in special cases Silicon and Viton.
We Normally Stock All Type of Soft (Sponge type) Edpm Packing in Stock Generally Used for Marine Hatch Door Water Tight Applications.
The standard packing sizes available are. (mm)
| A | B | A | B |
| 8 | 8 | 40 | 10 |
| 10 | 10 | 40 | 12 |
| 12 | 12 | 40 | 15 |
| 15 | 15 | 40 | 20 |
| 20 | 10 | 40 | 30 |
| 20 | 12 | 40 | 40 |
| 20 | 15 | 45 | 20 |
| 20 | 20 | 45 | 25 |
| 25 | 10 | 50 | 15 |
| 25 | 12 | 50 | 20 |
| 25 | 15 | 50 | 25 |
| 25 | 25 | 50 | 30 |
| 30 | 10 | 50 | 35 |
| 30 | 12 | 50 | 40 |
| 30 | 15 | 60 | 40 |
| 30 | 20 | 71 | 32 |
| 30 | 25 | 70 | 40 |
| 35 | 10 | 90 | 50 |
| 35 | 15 | 94 | 50 |
| 35 | 20 | 120 | 60 |
| 35 | 25 |
Rubber Profiles
The rubber stripes and profile are considered to be the most popular product in rubber extrusion production line
Description
Profiles and stripes are available in a variety of shapes, sizes, rubber materials. We manufacture both solid and sponge types.
Profiles are used as sealing components with anti-friction qualities for the smooth operation of windows and doors. These rubber profiles are extensively used in a vast range of diverse applications. These rubber profiles mainly serve as sealing components between the glass and aluminum sections.
Some examples of the profiles that we manufacture & Keep Stock are shown in the pictures below. Being Trader cum manufacturers, we design and develop rubber profiles to the specific requirements of our customers & In Different Polymers & hardness.
We Also Have Rubber Metal Co- extruded Profiles Mainly Used in Automotive & as Edge Protectors. Rubber Metal Profiles Are with Side or Top Bulb Used as a Protector & Cover the Sharp Edge of Metal plates. We Do Also Have Plain PVC Metal Trims To Protect Sharp Edges of Metal Plates Used In Electrical Panel Board & Many Other Industries.
Rubber Sheets
Description
Rubber Sheets used for industrial, packing, gaskets, sealant and mining purpose. Our range of sheets include black Color with or without insertions having smooth or rough surfaces.
They are available in thickness from 0.5mm to 50mm and width up to 1.2 meters with a temperature range of -40° C to +400° C conforming to international standards. These are made from various type Polymers and their blends: Natural Rubber, SBR, Neoprene, Nitrile, EPDM, Butyl, Viton, Silicon rubber etc.
Mats
Anti Fatigue Mats
A range of anti-fatigue and safety matting for use in areas where personnel are
required to stand for prolonged periods of time. They help to improve worker comfort, reduce fatigue, insulate from cold concrete floors and maintain staff productivity. Whether it’s a dry area or an area where slipping is a risk, we have a solution to meet most budgets.
Electrical Mats
Insulating matting are also known as dielectric carpets, and are used to protect people and parts of electrical equipment used in switchboards, transformers and other high voltage workplaces.
Coin Mats
Coin Mat, which is Ideal for Rubber Flooring, walkways, runners, loading areas, work benches, general purpose areas.
Rubber Mountings
Al Omran Rubber Trading Keeps Many Types of Rubber Mountings in Stock. A Local Brand VIBRO – UAE & POLYBOND- INDIA Are Main Brand & Many Products Are on Shelf as per Customer’s Needs & Specifications.
Description
Rubber Mountings Are Used in Engines, Generators as anti vibrators and in heavy Equipment’s, plants and machineries mainly to isolate vibrations from work surfaces, Reduce noise levels, absorb shock.
There Are Many Types Of Mountings Mainly – Conical mountings, Machine mountings, Bushes, Spherical mountings, Buffer mountings pads, Bobbins, Spring mounts, side bearer mounts, suspension components.
Mainly the Polymer or Rubber Used in Mountings Is Natural or Neoprene & in different Hardness to Suit the Load & Compression.
Hydraulic Clamps
A Brand of Our Own Manufacturing Company Based In INDIA Known as Alfomega.
Description
High-quality vibration-dampening clamps. Single, Double, Twin and Vertical/Horizontal Pipe Clamps available in MS, SS and Polyamide plates with Polypropylene, Aluminum and Polyamide body.
Sizes From 6mm To 168mm Dia ID In Various Plates On Shelf As Per Customer Need & Application.
Transmission Products
Description
A New Venture In Line Of Rubber Products Which Was Intiated By Our Late Founder Mr Alihussain Yakub Which Enable Us To Stock & Trade In Transmission Products Of Branded Companies Like LOVEJOY- INDIA, KTR- INDIA, FENNER- INDIA HRC- INDIA, HYDAX-INDIA, C-KING TAIWAN etc.
Our Stock Consists of flawless Industrial Jaws, Spacer Coupling, and Mounting Components.
Chains
Description
From a viewpoint based on its history and development, chain is a mechanical belt running over sprockets that can be used to transmit power or convey materials.
Hydraulic Seals
We Stock Many Types Of Seals Which Are Used Basically In Hydraulic & Pneumatic Applications.
Description
Mainly Seals Are in PU (Polyurethane), Rubber & Engineering Plastic Materials.
Usually We Stock Quality Products from Chinese & Taiwan Manufactures or Even We can Make As Per Need in Our Own Group Company Seals CNC Machine Room In UAE.
